12"
Showing all 15 results
-
12", DB Drive
DB Drive K1-12S4 12″ Subwoofer 600W
Specifications:
Max Power 600 watts @4ohm
RMS Power 250 watts
2″4 layer voice coil
Aluminum Former
Vac PP Cone with Polyether foam surround
Poly-Cotton Spider
Vac PP Dome
PVC Trim Ring/Gasket
Spring Terminals
47.5 oz Ferrite magnet
Stamped Steel Frame
Black Electro-plated Top and Bottom PlatesSKU: n/a -
12", DD Audio
DD Audio 712-D2 12″ Subwoofer
Budget-minded car audio lovers can now get affordable quality subs from a global leader. Our new DD AUDIO REDLINE is an import subwoofer line built with the same quality standards as our American-made lines, a favorite of audio enthusiasts. We’re hand-building these subs using the same DD Audio innovations, plus, parts tooled to our exact specifications to provide the performance we demand. The DD AUDIO REDLINE is only available from select dealers.
Technical Specs:
700 Series – 225 oz triple magnet,
3.0″ voice coil,
3 layer spider,
cast frame,
600-1200 RMS/3600 peak,
D2 – D4SKU: n/a -
12", DD Audio
DD Audio DD-812-D1 12″ Subwoofer
The 800 Series is aimed directly at the over the top bass cruising market. These subs get low and loud for an entire evening long cruise. The motor was designed around a humungorific 4 inch, high temperature, USA made, flat wire, aluminum voice coil. ?This monster subs also possesses features such as backplate venting, basket venting and outer shorting ring/heat sinking to ensure the highest long-term heat dissipation possible.The suspension is a combination of two DD Audio innovations. It utilizes a higher density EROM surround coupled with an exclusive multi-layer composite spider system. This style of suspension gives precise coil movement and long term durability under heavy use.The new 800 Series is some serious equipment made for the system designer who is going all out in the pursuit of the ultimate bass experience.800 Series Features:- Double Stitched EROM Surrounds
- High-temp 4.0?, aluminum former voice coil
- Laminated Spiders
- Non-pressed paper cones
- Cooling vent equipped cast aluminum baskets
- Back plate coil gap venting
- Extended pole piece
SPECS
MODEL 812 Driver Size – in 12 Power Band – Watts 1000 – 2000 Burst Power – Watts 6000 VCD – in 4 Impedance D1 / D2 Sd – in 10 Fs – Hz 37.68 Qms 5.218 Qes 0.493 Qts 0.451 Vas – cu ft 0.736 Xmech – mm 80 Xmax – mm 18 Cutout Diameter – in 11.25 Mounting Depth – in 7.625 Motor Diameter – in 9.5 Driver Displacement – cu ft 0.23 Shipping Weight – lbs 55.8 Sealed Enclosure – cu ft N/A Ported Enclosure – cu ft 1.75 – 2.75 SKU: n/a -
12", DD Audio
DD Audio DD512-D2 12″ Subwoofer
The 500 series is one of the best performing subs you can find in its power class. With a highly efficient design, the 500 series can easily be driven to high output levels on as little as 150-400 Watts. The 500s are very versatile subs with their?laminated double layer poly cotton spider allows them to work well in sealed enclosures, and its double stack magnet provides the extra energy needed for vented enclosures applications.
500 Series Features:
- Double Stitched EROM Surrounds
- High-temp 2.0?, aluminum former voice coil
- 150w-400w RMS, 1200w Peak
- Laminated Spiders
- Non-pressed paper cones
- Cooling vent equipped baskets
- Back plate coil gap venting
- Extended pole piece
SPECS
MODEL 512C Driver Size – in 12 Power Band – Watts 150 – 400 Burst Power – Watts 1200 VCD – in 2 Impedance D2 / D4 Sd – in 10 Fs – Hz 36.34 Qms 6.582 Qes 0.840 Qts 0.745 Vas – cu ft 1.194 Xmech – mm 64 Xmax – mm 11 Cutout Diameter – in 11.125 Mounting Depth – in 5.688 Motor Diameter – in 6 Driver Displacement – cu ft 0.09 Shipping Weight – lbs 15 Sealed Enclosure – cu ft 0.5 – 1.0 Ported Enclosure – cu ft 1.75 – 2.75 SKU: n/a -
12", DD Audio
DD Audio DD612-D2 12″ Subwoofer
The 600 Series is a great entry point for a higher performance system design that keeps the vehicle as close to stock as possible. The 600 Series will perform like a boss on as little as 300-600 Watts rms, meaning even multiple woofer systems can be driven with one moderate powered amplifier. This keeps electrical upgrades minimal with less added strain on the vehicle. It has a high energy, double stack motor paired with a laminated triple layer poly cotton spider suspension. The 600 Series works best with vented and multi-order?enclosures.
600 Series Features:
-
The 600 series woofers features:
- Double Stitched EROM Surrounds
- High-temp 2.5?, aluminum former voice coil
- 300W-600W RMS
- 1800W Peak
- Triple Layer Laminated Spiders
- Non-pressed paper cones
- Stamped steel basket with cooling vents (note : the 8″ has a cast aluminum basket)
- 10-AWG Push Terminals
- Back plate coil gap venting
- 3-Way cooling
- Extended pole piece
- 110oz double stack magnet
SPECS
MODEL 612 Driver Size – in 12 Power Band – Watts 300 – 600 Burst Power – Watts 1800 VCD – in 2.5 Impedance D2 / D4 Sd – in 10 Fs – Hz 37.68 Qms 6.305 Qes 0.692 Qts 0.624 Vas – cu ft 0.914 Xmech – mm 64 Xmax – mm 13 Cutout Diameter – in 11.125 Mounting Depth – in 5.938 Motor Diameter – in 6.375 Driver Displacement – cu ft 0.09 Shipping Weight – lbs 18 Sealed Enclosure – cu ft N/A Ported Enclosure – cu ft 1.75 – 2.75 SKU: n/a -
-
12", Fusion
Fusion Performance PF-SW120D2 12″ Subwoofer
Specifications
Mounting Dimensions
Mounting Depth 158mm (6-1/4″) Mounting Diameter 279mm (11″) Product Specifications
Basket Pressed Steel Cone Material Pressed Paper Frequency Response 30Hz – 1.2kHz Peak Power (Watts) 1600 Rated Power (Watts) 400 Sensitivity (dB) 89 Surround Material Butyl Rubber Thiele Small Parameters
Compliance (Cms) (?M/N) 112.00u M/N Cone Area (Sd) (cm?) 530.93 Cone Area (Sd) (In?) 82.29 D.C. Coil Resistance (Re) (?) 4.47 Ohm Electrical Q (Qes) 0.84 Force Factor (Bl) (TM) 14.04 Free Air Resonance (Fs) 38.30 Linear Excurson (Xmax) (In) 0.24 Linear Excurson (Xmax) (mm) 6.00 Mechanical Excursion (In) 0.35 Mechanical Excursion (mm) 9.00 Mechanical Q (Qms) 2.93 Total Loudspeaker Q (Qts) 0.65 VAS (CuFt) 1.58 VAS (L) 44.69 Voice Coil Impedance 2 x 2 Ohm SKU: n/a -
12", Pioneer
Pioneer TS-W311D4 12″ Dual Voice Coil Subwoofer (1400W)
More bass. More power. Greater flexibility.
Get powerful, punchy bass in your car ? from the pedigree of world record-breaking subs.
The TS-W310D4 features a combined IMPP cone, which makes the body ultra-rigid yet lightweight, giving you low distortion and powerful bass at high sound press levels.
MPP Composite Seamless Cone
An extremely durable, yet lightweight cone is vital to prevent cone failure at high sound pressure levels. Pioneer?s New IMPP Composite Seamless Cones meet this need perfectly while delivering accurate yet powerful bass.
Dual-Layer Elastic Polymer Surround
Another world?s first from Pioneer. Dramatically improves durability and lightness for superior response, especially for louder volume.Large Surface Area
A speaker cone is essential for air to vibrate and carry sound to listeners? ears. Our Champion Series subwoofer cones have 14% more surface area than conventional subwoofer cones, for louder, better bass reproduction.Single/Dual Voice Coil Design
Pioneer offers single voice coil and dual voice coil designs. The Dual 4 ? subwoofer has the flexibility to be wired at 2 or 8 ?, to get the most from the amplifier. To simplify installation even further, all speaker terminals have been placed on one side of the subwoofer rather than on opposite sides.Air Vent
The movement of air within the subwoofer is smoothly channeled for optimal ventilation to ensure a quick response and clear reproduction of bass.Other Features
? Extra-tough suspension for high durability to withstand high input power.
? 4-Layer Copper voice coil with aluminium former for improved heat dissipation.
? Subwoofer design allows for flexible in-car installation in a box or in a free-air type application.Features
-
Maximum input power1.400?W
-
Nominal input power400?W
-
Impedance2? / 8?
-
Frequency response20 ? 250?Hz
-
Sensitivity (1W/1m)95?dB
-
Woofer size30,0?cm
-
Woofer materialIMPP Composite Seamless Cone
-
Voice Coil typeDual
-
Dual 4? voice coils: 2 or 8?
-
Pole Yoke TypeExtended and Vented pole yoke
-
TerminalsPush-type
-
Weight6.2 kg
-
SurroundDual Layer, Fiber Reinforced Elastic Polymer Surround
Thiele/Small Parameters
-
Qts0,77
-
Fs [Hz]37
-
Vas [ft3]1,21
-
Xmax [mm]10,8
-
Xmax [in]0,42
SKU: n/a -
-
12", Rockford Fosgate
Rockford Fosgate P1S2-12 12? Punch P1 2-Ohm SVC Subwoofer
Rockford Fosgate P1 12? is the first in a family of famous ?Punch? subwoofers. The P1S2-12 features a 2-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included soft touch ABS trim ring.
- Linear spider with embedded 16 AWG tinsel leads
- High-temp voice coil with spun-laced Nomex? re-inforcement collar
- Kevlar fiber reinforced paper cone
- StampCast basket with integrated spider venting
- Soft touch ABS trim ring with optional grille
- Custom 10-AWG nickel plated push terminals
- Extended pole piece and bumped vented backplate
- Protective PVC textured magnet cover
SKU: n/a -
12", Rockford Fosgate
Rockford Fosgate P2D4-12″ Subwoofer
his P2 sub features an extended pole piece and bumped backplate that leaves more room for heavy excursion, so it’ll hit deeper lows without “bottoming out.” Special venting keeps the copper-clad aluminum voice coils cool through heavy use for consistent bass performance over time.
The dual 4-ohm voice coils allow you to wire the sub for 2-ohm impedance to work with a mono sub amp, or for 8-ohm impedance if you’re using multiple subs. The P2D4-12 sub works equally well in a sealed or ported enclosure, so you can choose the kind of bass you want for your system.
To drive this single subwoofer, we recommend a mono amplifier rated between 300 and 600 watts RMS at 2 ohms.
Product Highlights:
- 12″ subwoofer with dual 4-ohm voice coils
- Kevlar? reinforced paper cone
- Santoprene surround
- hybrid StampCast basket provides strength while minimizing weight and resonance
- power range: 150-400 watts RMS (800 watts peak power)
- frequency response: 27-250 Hz
- sensitivity: 86 dB
- top-mount depth: 6-3/8″
- sealed box volume: 0.70-1.80 cubic feet
- ported box volume: 1.79 cubic feet
SKU: n/a
