12", DD Audio
DD Audio DD612-D2 12″ Subwoofer
The 600 Series is a great entry point for a higher performance system design that keeps the vehicle as close to stock as possible. The 600 Series will perform like a boss on as little as 300-600 Watts rms, meaning even multiple woofer systems can be driven with one moderate powered amplifier. This keeps electrical upgrades minimal with less added strain on the vehicle. It has a high energy, double stack motor paired with a laminated triple layer poly cotton spider suspension. The 600 Series works best with vented and multi-order?enclosures.
600 Series Features:
-
The 600 series woofers features:
- Double Stitched EROM Surrounds
- High-temp 2.5?, aluminum former voice coil
- 300W-600W RMS
- 1800W Peak
- Triple Layer Laminated Spiders
- Non-pressed paper cones
- Stamped steel basket with cooling vents (note : the 8″ has a cast aluminum basket)
- 10-AWG Push Terminals
- Back plate coil gap venting
- 3-Way cooling
- Extended pole piece
- 110oz double stack magnet
SPECS
MODEL 612 Driver Size – in 12 Power Band – Watts 300 – 600 Burst Power – Watts 1800 VCD – in 2.5 Impedance D2 / D4 Sd – in 10 Fs – Hz 37.68 Qms 6.305 Qes 0.692 Qts 0.624 Vas – cu ft 0.914 Xmech – mm 64 Xmax – mm 13 Cutout Diameter – in 11.125 Mounting Depth – in 5.938 Motor Diameter – in 6.375 Driver Displacement – cu ft 0.09 Shipping Weight – lbs 18 Sealed Enclosure – cu ft N/A Ported Enclosure – cu ft 1.75 – 2.75 SKU: n/a -
-
12", Fusion
Fusion Performance PF-SW120D2 12″ Subwoofer
Specifications
Mounting Dimensions
Mounting Depth 158mm (6-1/4″) Mounting Diameter 279mm (11″) Product Specifications
Basket Pressed Steel Cone Material Pressed Paper Frequency Response 30Hz – 1.2kHz Peak Power (Watts) 1600 Rated Power (Watts) 400 Sensitivity (dB) 89 Surround Material Butyl Rubber Thiele Small Parameters
Compliance (Cms) (?M/N) 112.00u M/N Cone Area (Sd) (cm?) 530.93 Cone Area (Sd) (In?) 82.29 D.C. Coil Resistance (Re) (?) 4.47 Ohm Electrical Q (Qes) 0.84 Force Factor (Bl) (TM) 14.04 Free Air Resonance (Fs) 38.30 Linear Excurson (Xmax) (In) 0.24 Linear Excurson (Xmax) (mm) 6.00 Mechanical Excursion (In) 0.35 Mechanical Excursion (mm) 9.00 Mechanical Q (Qms) 2.93 Total Loudspeaker Q (Qts) 0.65 VAS (CuFt) 1.58 VAS (L) 44.69 Voice Coil Impedance 2 x 2 Ohm SKU: n/a
