Component, Fusion
Fusion 6.5″ Component Speaker System
Specifications
Mounting Dimensions
Mounting Depth 65mm 2.6″ Mounting Diameter 140mm 5.5″ Product Specifications
Cone Material CURV Frequency Response 40Hz-22kHz Peak Power (Watts) 340 Rated Power (Watts) 120 Sensitivity (dB) 91 Thiele Small Parameters
Compliance (Cms) (?M/N) 582.45 Cone Area (Sd) (cm?) 128.68 D.C. Coil Resistance (Re) (Ohm) 3.2 Electrical Q (Qes) 0.495 Force Factor (Bl) (TM) 5.418 Free Air Resonance (Fs) 60 Mechanical Q (Qms) 2.989 Total Loudspeaker Q (Qts) 0.425 Voice Coil Impedance 4 Ohm Tweeter Specifications
Tweeter Type Titanium SKU: n/a -
Component, Focal
Focal PS 165 F FLAX CONE 6”1/2 2-WAY COMPONENT KIT
The 6”1/2 woofer has the new flax cone for a neutral sound without coloration, more dynamique, natural reproduction.
This kit benefits from a new design: the baskets are in Black Mat Aluminium engraved with Focal’s logo and ally modernism and tradition.
Processed Aluminum/Magnesium inverted dome tweeter for smoothness and definition without directivity. The tweeter is equipped with the new poron suspension for long life.
Product Specifications:
Diameter: 61/2?? (165mm)
Mounting depth: 27/8?? (72.5mm)
Voice-coil diameter: 1?? (25mm)
Voice-coil height: 09/6?? (15mm)
Magnet: 31/3?? (85mm)
Processed Aluminum/Magnesium inverted
dome tweeter
Cone : Flax?
Separated crossover: 12-12dB/Oct
Ajustable tweeter level: 0; -3dB/Oct
Max. power: 140 W
Nom. power: 70 WRMS
Sensitivity (2.83V/1m): 91.6dB
Frequency response: 60Hz-28kHz
Accessories: Supplied grillesSKU: n/a
