Monoblock, Pioneer
Pioneer GM-D9601 Mono 2400W Class-D Car Amp, with Bass Boost Remote
-
Maximum Output Power?1 x 1000 W (4?)
1 x 1600 W (2?)
1 x 2400 W (1?) -
CEA 2006 Power (THD N = 1%)1 x 500 W (100 Hz / 2?)
1 x 800 W (100 Hz / 2?)
1 x 1200 W (50 Hz / 2?)
75 dBA (ref: 1 W into 4?) -
Continuous power output (RMS)1 x 500 W RMS (4?)
1 x 800 W RMS (2?)
1 x 1200 W RMS (1?) -
Frequency response10 ? 240?Hz
-
Distortion10W, 100 Hz ref. < 0.5?%
-
S/N ratio> 100?dB
-
Bass BoostRemote Control
Frequency 50 Hz, Level 0-18 dB -
LPF40 ? 240 Hz (-12 dB/oct)
-
RCA terminals
-
Speaker TerminalsBlock-type
-
Speaker line input sensorturn-on sensor
-
Input level controlRCA (0.2V ? 6.5V)
SP (0.8V ? 16V) -
Max. current consumption (A/4?)39 A
-
Chassis size (W x H x D)315 x 60 x 200 ?mm
-
Unit weight3.3 ?kg
SKU: n/a -
-
Monoblock, DD Audio
DD Audio M1D Monoblock Amplifier 1700w x 1 @ 1 Ohm
The M1 is one of our most popular amps of all time, and it is now entering its 5th generation. The M1d is the perfect amp for a myriad of applications, delivering over 1200 Watts of true RMS power at 12 Volts, 1700 Watts continuous at 14.4 Volts, and over 2500 Watts dynamic power. The compact layout uses our LV type twin power supply, which keeps the chassis small and the power big while allowing for a plethora of mounting options. 0 Gauge power connections and through bolted RCAs provided high-end features at an affordable price.
For installation ease, and upgradeability the M1d features Strap and Link mode. When using one of these modes you’re able to use multiple M1d in an install and control the Strapped or Linked amplifiers level settings from the main. You’ll also be able to use a single remote gain to control all strapped and linked amps.
The M1d also comes with the VM-RMT remote control. The VM-RMT is a mini amplifier diagnostic center that’s able to mount within arms reach for real-time performance monitoring and adjustments. From this remote you have fine gain control, amplifier input voltage monitoring, and output clipping monitoring.
SPECS
Test Voltage 12 / 14.4
Channels 1
Cont Wattage @ 4ohm N/A
Cont Wattage @ 2ohm N/A
Cont Wattage @ 1ohm 1,200×1@12V / 1,700×1@14.4V
Dynamic Wattage 2,500×1
Max Current Draw – Amperage 170
S/N Ratio >100dB
THD <0.2% Input Voltage Sensitivity 8 - 0.2 Pass-Through Output Yes Remote Subwoofer Control Yes Power Wire Guage In 1 x 0 Speaker Wire Gauge Out 10 Dimensions: in 13.77 x 3.88 x 2.14 Dimensions: mm 350 x 175 x 54.5 Shipping Weight - lbs 11SKU: n/a
