DD Audio DD-812-D1 12″ Subwoofer
Out of stock
- Double Stitched EROM Surrounds
- High-temp 4.0?, aluminum former voice coil
- Laminated Spiders
- Non-pressed paper cones
- Cooling vent equipped cast aluminum baskets
- Back plate coil gap venting
- Extended pole piece
SPECS
| MODEL | 812 | ||
| Driver Size – in | 12 | ||
| Power Band – Watts | 1000 – 2000 | ||
| Burst Power – Watts | 6000 | ||
| VCD – in | 4 | ||
| Impedance | D1 / D2 | ||
| Sd – in | 10 | ||
| Fs – Hz | 37.68 | ||
| Qms | 5.218 | ||
| Qes | 0.493 | ||
| Qts | 0.451 | ||
| Vas – cu ft | 0.736 | ||
| Xmech – mm | 80 | ||
| Xmax – mm | 18 | ||
| Cutout Diameter – in | 11.25 | ||
| Mounting Depth – in | 7.625 | ||
| Motor Diameter – in | 9.5 | ||
| Driver Displacement – cu ft | 0.23 | ||
| Shipping Weight – lbs | 55.8 | ||
| Sealed Enclosure – cu ft | N/A | ||
| Ported Enclosure – cu ft | 1.75 – 2.75 |
$769 $870
Out of stock
Related products
-
Component, DD Audio
DD Audio DC6X9 D CLASS 6X9 COMPONENT SET
he D Class 6×9 Component set consists of high tech, high fidelity drivers designed for the listener wanting to go well beyond the standard factory upgrade.
Woofer:
Our focus on sound quality starts with precision motor assemblies. The machined magnet gaps driven with high energy strontium magnets provide strong output from a compact design. We incorporated distortion reducing copper shorting rings for flux modulation and inductance control. The aluminum mid woofer cones achieve wide bandwidth and efficient energy transfer to the air. The compressed rubber surrounds are durable and have been optimized for light weight to increase sensitivity.
Tweeter:
The tweeter side of the D Class component sets is our T2a 25mm ultra-light diaphragm tweeter. This new diaphragm is less than 0.003 of an inch thick; that’s almost nothing of a mm. This proprietary fabric is so thin it’s virtually see through, well, actually it is see through. The ultra-light dome is coupled to a low-distortion, neo motor with flush/surface mounting hardware and metal grill options.
Crossover:
The 2-way crossover features low distortion coils and metalized polypropylene caps that pass the source without degradation. The D Class components are purposefully built, enthusiast quality sets — everything you need for great sound and nothing you don’t.
SPECS
Driver Size – in Woofer 6×9 / Tweeter 25mm
Power Band – Watts 50-150
Impedance S4
Frequency Response – Hz 40-25k
dBSPL 90
Cutout Diameter – in 5.96 x 8.61
Mounting Depth – in 2.39
Shipping Weight – lbs 10Note: Any DD Audio Product bearing the Marine Grade logo incorporates water resistant features enabling it to be used in applications where moderate exposure to moisture will not result in damage to the product.
Marine Grade products are not waterproof, and submersion or excessive moisture exposure may result in product failure. DD Audio Marine Grade products are not certified for saltwater environments.
SKU: n/a -
Component, DD Audio
DD Audio CC6.5 A 6.5″ High Quality Component Set
Audibly Refined| 6.5″ High Quality Component Set
The C Class 2-Way Component System is the perfect balance of high-fidelity refinement and value.
Mid-Woofer
The 6.5-in mid-woofer features a coated paper cone that provides warm tonal characteristics with added environmental element resistance for the mobile environment. The surround is made of a lightweight rubber compound that adds durability without sacrificing any sound. For the frame, we used a sexy low resonance cast aluminum frame. For reduced inductance, extended high-frequency roll off , and increased efficiency the voice coils feature a double slit former and the motor utilizes a copper pole cap . The soft parts are driven with a high flux 17 Oz ferrite magnet motor.Tweeter
The 25-mm silk dome tweeter features a vented back for a wider/smoother frequency response.Crossover
The Crossover networks are built with premium components, including Mylar capacitors, segmented air-core inductors and poly fuses for tweeter protection. Three selectable tweeter levels are provided for fine high-frequency tuning.Driver Size – in
Woofer 6.5 / Tweeter 25mm
Power Band – Watts
60-180
Impedance
S4
Frequency Response – Hz
50-20k
Cutout Diameter – in
Woofer 5.73 / Tweeter 1.65
Mounting Depth – in
Woofer 2.67 / Tweeter 0.47
Shipping Weight – lbs
10Any DD Audio Product bearing the Marine Grade logo incorporates water resistant features enabling it to be used in applications where moderate exposure to moisture will not result in damage to the product.
Marine Grade products are not waterproof, and submersion or excessive moisture exposure may result in product failure. DD Audio Marine Grade products are not certified for saltwater environments.
Copper Capped Pole Piece
As current flows through the voice coil, it generates its own magnetic field which interacts, or modulates the motors permanent magnet field. A shorting ring cancels these magnetic field changes and lowers inductance, extending the frequency range and reducing harmonic distortion.Aluminum – Double Slit Voice Coil Former
The aluminum former material acts as a heat sink, lowering the voice coil temperature. The double slits in the former break up and reduce magnetic eddy currents generated by the moving coil. The coil design works in conjunction with the copper capped pole piece to further reduce heat, inductance, and harmonic distortions.SKU: n/a -
12", DD Audio
DD Audio DD512-D2 12″ Subwoofer
The 500 series is one of the best performing subs you can find in its power class. With a highly efficient design, the 500 series can easily be driven to high output levels on as little as 150-400 Watts. The 500s are very versatile subs with their?laminated double layer poly cotton spider allows them to work well in sealed enclosures, and its double stack magnet provides the extra energy needed for vented enclosures applications.
500 Series Features:
- Double Stitched EROM Surrounds
- High-temp 2.0?, aluminum former voice coil
- 150w-400w RMS, 1200w Peak
- Laminated Spiders
- Non-pressed paper cones
- Cooling vent equipped baskets
- Back plate coil gap venting
- Extended pole piece
SPECS
MODEL 512C Driver Size – in 12 Power Band – Watts 150 – 400 Burst Power – Watts 1200 VCD – in 2 Impedance D2 / D4 Sd – in 10 Fs – Hz 36.34 Qms 6.582 Qes 0.840 Qts 0.745 Vas – cu ft 1.194 Xmech – mm 64 Xmax – mm 11 Cutout Diameter – in 11.125 Mounting Depth – in 5.688 Motor Diameter – in 6 Driver Displacement – cu ft 0.09 Shipping Weight – lbs 15 Sealed Enclosure – cu ft 0.5 – 1.0 Ported Enclosure – cu ft 1.75 – 2.75 SKU: n/a
