6", Focal
Focal PS 165 FX FLAX CONE 6”1/2 / 2-WAY COMPONENT KIT
The 6”1/2 woofer has the new flax cone for a neutral sound without coloration, more dynamique, natural reproduction hung by a Butyl surround with an excellent reliability. The phase plug in the center of the cone also offer a better dispersion than the PS 165 F woofer.
Processed Aluminum/Magnesium inverted dome tweeter for smoothness and definition without directivity. The tweeter is equipped with the new poron suspension for long life.
The speakers are plugged to a powerful bi amp crossover.
Product Specifications:
Diameter: 61/2?? (165mm)
Mounting depth: 31/16?? (77mm)
Voice-coil diameter: 11/4?? (32mm)
Voice-coil height: 09/6?? (15mm)
Magnet: 39/6?? (90mm)
Processed Aluminum/Magnesium inverted
dome tweeter
Cone : Flax?
Separated crossover: 12-18dB/Oct
Ajustable tweeters level: 0 ;-3dB/Oct
Max. power: 160 W
Nom. power: 80 WRMS
Sensitivity (2.83V/1m): 91.3dB
Frequency response: 55Hz-28kHz
Accessories: Supplied grillesSKU: n/a -
12", Pioneer
Pioneer TS-W311D4 12″ Dual Voice Coil Subwoofer (1400W)
More bass. More power. Greater flexibility.
Get powerful, punchy bass in your car ? from the pedigree of world record-breaking subs.
The TS-W310D4 features a combined IMPP cone, which makes the body ultra-rigid yet lightweight, giving you low distortion and powerful bass at high sound press levels.
MPP Composite Seamless Cone
An extremely durable, yet lightweight cone is vital to prevent cone failure at high sound pressure levels. Pioneer?s New IMPP Composite Seamless Cones meet this need perfectly while delivering accurate yet powerful bass.
Dual-Layer Elastic Polymer Surround
Another world?s first from Pioneer. Dramatically improves durability and lightness for superior response, especially for louder volume.Large Surface Area
A speaker cone is essential for air to vibrate and carry sound to listeners? ears. Our Champion Series subwoofer cones have 14% more surface area than conventional subwoofer cones, for louder, better bass reproduction.Single/Dual Voice Coil Design
Pioneer offers single voice coil and dual voice coil designs. The Dual 4 ? subwoofer has the flexibility to be wired at 2 or 8 ?, to get the most from the amplifier. To simplify installation even further, all speaker terminals have been placed on one side of the subwoofer rather than on opposite sides.Air Vent
The movement of air within the subwoofer is smoothly channeled for optimal ventilation to ensure a quick response and clear reproduction of bass.Other Features
? Extra-tough suspension for high durability to withstand high input power.
? 4-Layer Copper voice coil with aluminium former for improved heat dissipation.
? Subwoofer design allows for flexible in-car installation in a box or in a free-air type application.Features
-
Maximum input power1.400?W
-
Nominal input power400?W
-
Impedance2? / 8?
-
Frequency response20 ? 250?Hz
-
Sensitivity (1W/1m)95?dB
-
Woofer size30,0?cm
-
Woofer materialIMPP Composite Seamless Cone
-
Voice Coil typeDual
-
Dual 4? voice coils: 2 or 8?
-
Pole Yoke TypeExtended and Vented pole yoke
-
TerminalsPush-type
-
Weight6.2 kg
-
SurroundDual Layer, Fiber Reinforced Elastic Polymer Surround
Thiele/Small Parameters
-
Qts0,77
-
Fs [Hz]37
-
Vas [ft3]1,21
-
Xmax [mm]10,8
-
Xmax [in]0,42
SKU: n/a -
-
Monoblock, Pioneer
Pioneer GM-D9601 Mono 2400W Class-D Car Amp, with Bass Boost Remote
-
Maximum Output Power?1 x 1000 W (4?)
1 x 1600 W (2?)
1 x 2400 W (1?) -
CEA 2006 Power (THD N = 1%)1 x 500 W (100 Hz / 2?)
1 x 800 W (100 Hz / 2?)
1 x 1200 W (50 Hz / 2?)
75 dBA (ref: 1 W into 4?) -
Continuous power output (RMS)1 x 500 W RMS (4?)
1 x 800 W RMS (2?)
1 x 1200 W RMS (1?) -
Frequency response10 ? 240?Hz
-
Distortion10W, 100 Hz ref. < 0.5?%
-
S/N ratio> 100?dB
-
Bass BoostRemote Control
Frequency 50 Hz, Level 0-18 dB -
LPF40 ? 240 Hz (-12 dB/oct)
-
RCA terminals
-
Speaker TerminalsBlock-type
-
Speaker line input sensorturn-on sensor
-
Input level controlRCA (0.2V ? 6.5V)
SP (0.8V ? 16V) -
Max. current consumption (A/4?)39 A
-
Chassis size (W x H x D)315 x 60 x 200 ?mm
-
Unit weight3.3 ?kg
SKU: n/a -
-
5" x 7", Pioneer
Pioneer TS-A6886R 6″x8″ 4-Way Car Speakers
Pioneer’s pumped-up TS-A Series TS-A6886R 6″x8″ 4-way speakers give you a powerful speaker solution with a friendly price tag so that you don’t go over budget building a whole system. Pair these puppies with a new car stereo for a refreshing sonic upgrade, or go all the way and power them with an outboard amp. Either way, these Pioneers will handle up to 60 watts RMS, so you’ll have a high ceiling for cranking your jams.
Listen with authority
These speakers deliver a satisfying punch, thanks to a woofer cone made of reinforced mica for rigidity and responsiveness. Pioneer adds an extra midrange driver so you get the most out of chunky guitar riffs, powerful drums, and distinct bass lines that otherwise would remain hidden when listening on sub-par speakers. Two dome tweeters add in all the high-frequency details that make music exciting.Product Highlights:
6″x8″ 4-way car speakers (pair)
multilayer mica-matrix woofer with elastic polymer surround
1-5/8″ paper cone midrange
3/8″ PET (Polyethylene Terephthalate) dome tweeter and supertweeter
power range: 5-60 watts RMS (350 watts peak power)
frequency response: 28-39,000 Hz
sensitivity: 91 dB
top-mount depth: 2-3/8″SKU: n/a
